Glass Raw Material Dry Powder Mixer Machine

FOB Reference Price:Get Latest Price
1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Product Type:
Dry powder
Place of Origin:
Shandong, China (Mainland)
Brand Name:
LT
Model Number:
LT-LSHJ-750L
Dynamic type:
Electric
Construction:
Vertical
Working mode:
Continuous
Mixing tank shape:
Cylinder
Mixing capacity:
3-4ton/h
Power:
18.5kw
Reference weight:
2350kg
Color:
As customer's request
Machine Type:
Planet mixer
Supply Ability
Supply Ability:
20 Set/Sets per Month
Packaging & Delivery
Packaging Details
Export packing
Port
Qingdao port

Features:

1.Mixing is more homogeneous and loose;

2.Convenient for discharging;

3.Easy to clean;

4.High efficiency;

5.The equipment is not easy to wear.



Application:

Mixer is the necessary equipment for the production of ceramic frit, sodium silicate, and widely applied in glass industry, which is mainly used to mix powder materials to meet the demand for production.



Main technical data:

1.Granularity: powder material

2.Maximum volume: 750L

3.Turboprop rate: 29r/min

4.Opening angle of discharging: 1200

5. Power: 18.5KW

6.Reduction ratio:1:35

7. Plant reference size: 2130×2100×2591mm

8.Reference weight: 2350KG



Composition parts:

1. Discharging opening

2. Mixing tank

3. Turboprop

4. Lubricating Setting

5. Upper cover

6. Reducer

7. Discharging setting



Operation cycle description:

First, the turboprop is driven by the reducer over the mixer, then material should be added into the mixer after it’s running. Therefore, raw materials are mixed as uniform material in the mixer and then discharged through the opening. Then, the discharging opening is closed, and the operation cycle finishes.
